Cavity Fire Barrier
TDSCCFB
PFC Corofil Cavity Fire Barrier CCFB is a full fill cavity fire barrier manufactured from a 100mm thick low density stone wool product installed between the inner and outer substrates of a masonry façade to reinstate the fire resistance performance of the cavity. The lighter density allows greater scope for compression when installing within brickwork cavities when using wet mortar.
PFC Corofil cavity Fire Barrier has been tested to EN1366-4:2021 and will provide up to 120 minutes integrity and 60 minutes insulation fire resistance performance (please see the tables on page 4 for the full fire resistance performance based on cavity widths and orientation).
Intended use
PFC Corofil Cavity Fire Barrier CCFB is designed and tested for installation within masonry cavities up to 300mm wide to reinstate the fire resistance performance of the cavity, whilst allowing greater scope for compression when installing in masonry cavities using wet mortar.
This data sheet shows the only applications the product has been tested in. Please ensure the product has been tested in and is suitable for your application (see PFC Corofil terms and conditions 13.1.1).
Key points:
- Tested to EN1366-4:2021
- Suitable for masonry cavities up to 300mm
- Allows greater compression when installing in cavities with wet mortar
